Data exporter

Mage natively supports integration with a variety of data storage systems. However, these integrations often require specific configurations in both the exporter block and the io_config.yml file to ensure seamless operation. The io_config.yml file typically includes connection details such as host, port, database name, username, and password. Meanwhile, the exporter block needs to be configured with the appropriate export parameters, such as target table names, schema details, and conflict resolution strategies.

Technical Details

Data Exporter Blocks:
- These blocks are designed to facilitate the movement of transformed data or trained models to external systems.
- Configuration parameters might include destination paths, file formats, table names, schemas, and update strategies.
- Most data exporters include a config_profile parameter set to 'default' by default. This parameter can be customized to use different configuration profiles if you have multiple profiles or have renamed them.
Supported Data Storage Systems:
- Mage supports a wide range of storage systems including PostgreSQL, MySQL, AWS S3, Google Cloud Storage, Azure Blob Storage, and many more.
- Each system may have unique requirements and configurations to ensure compatibility and optimal performance.
Configuration in io_config.yml:
- This file serves as the central configuration hub for defining connection parameters.
- Typical parameters include:
  - host: The server address of the storage system.
  - port: The port number for the connection.
  - database: The name of the target database or data storage container.
  - username and password: Authentication credentials.
  - Additional parameters as required by specific storage systems (e.g., SSL settings, API tokens).

Examples

Data Warehouse

Configure the io_config.yml file to connect your Mage pipeline to a snowflake data warehouse. While optional, depending on how your Snowflake DW is configured you may need to enter all information into the .yml file. It’s recommended to store sensitive information as Secrets. See the general Secrets documentation for more information.

  SNOWFLAKE_USER: username
  SNOWFLAKE_PASSWORD: password
  SNOWFLAKE_ACCOUNT: account_id.region
  SNOWFLAKE_DEFAULT_WH: null                  # Optional default warehouse
  SNOWFLAKE_DEFAULT_DB: null                  # Optional default database
  SNOWFLAKE_DEFAULT_SCHEMA: null              # Optional default schema
  SNOWFLAKE_PRIVATE_KEY_PASSPHRASE: null      # Optional private key passphrase
  SNOWFLAKE_PRIVATE_KEY_PATH: null            # Optional private key path
  SNOWFLAKE_ROLE: null                        # Optional role name
  SNOWFLAKE_TIMEOUT: null                     # Optional timeout in seconds

Enter information for the following in the Data Exporter block

table_name - requires developers enter the name of their destination table
database - requires developers enter the name of their destination data base
schema - requires developers enter the name of their destination schema

All other information is handled in the ‘io_config.yml’ file.

Example Code:

from mage_ai.settings.repo import get_repo_path
from mage_ai.io.config import ConfigFileLoader
from mage_ai.io.snowflake import Snowflake
from pandas import DataFrame
from os import path

if 'data_exporter' not in globals():
    from mage_ai.data_preparation.decorators import data_exporter


@data_exporter
def export_data_to_snowflake(df: DataFrame, **kwargs) -> None:
    """
    Template for exporting data to a Snowflake warehouse.
    Specify your configuration settings in 'io_config.yaml'.

    Docs: https://docs.mage.ai/design/data-loading#snowflake
    """
    table_name = 'your_table_name'
    database = 'your_database_name'
    schema = 'your_schema_name'
    config_path = path.join(get_repo_path(), 'io_config.yaml')
    config_profile = 'default'

    with Snowflake.with_config(ConfigFileLoader(config_path, config_profile)) as loader:
        loader.export(
            df,
            table_name,
            database,
            schema,
            if_exists='replace',  # Specify resolution policy if table already exists
        )

Data Lake

Configure the io_config.yml file to connect your Mage pipeline to a Azure Blob Storage. Configure some Secrets and enter them into io_config.yml file. If you need more information on entering secrets see this documentation.

  AZURE_CLIENT_ID: "{{ env_var('AZURE_CLIENT_ID') }}"
  AZURE_CLIENT_SECRET: "{{ env_var('AZURE_CLIENT_SECRET') }}"
  AZURE_STORAGE_ACCOUNT_NAME: "{{ env_var('AZURE_STORAGE_ACCOUNT_NAME') }}"
  AZURE_TENANT_ID: "{{ env_var('AZURE_TENANT_ID') }}"

Enter information for the following in the Data Exporter block

container_name - requires developers enter the name of their destination container
blob_path - requires developers enter the name of their destination blob path

All other information is handled in the io_config.yml file.

Example Code:

from mage_ai.settings.repo import get_repo_path
from mage_ai.io.azure_blob_storage import AzureBlobStorage
from mage_ai.io.config import ConfigFileLoader
from pandas import DataFrame
from os import path

if 'data_exporter' not in globals():
    from mage_ai.data_preparation.decorators import data_exporter


@data_exporter
def export_data_to_azure_blob_storage(df: DataFrame, **kwargs) -> None:
    """
    Template for exporting data to a Azure Blob Storage.
    Specify your configuration settings in 'io_config.yaml'.

    Docs: https://docs.mage.ai/design/data-loading
    """
    config_path = path.join(get_repo_path(), 'io_config.yaml')
    config_profile = 'default'

    container_name = 'your_container_name'
    blob_path = 'your_blob_path'

    AzureBlobStorage.with_config(ConfigFileLoader(config_path, config_profile)).export(
        df,
        container_name,
        blob_path,
    )

Database

Configure the io_config.yml file to connect your Mage pipeline to a PostgreSQL database. Configure some Secrets and enter them into io_config.yml file. If you need more information on entering secrets see this documentation.

  POSTGRES_CONNECT_TIMEOUT: 10
  POSTGRES_DBNAME: postgres
  POSTGRES_SCHEMA: public # Optional
  POSTGRES_USER: username
  POSTGRES_PASSWORD: password
  POSTGRES_HOST: hostname
  POSTGRES_PORT: 5432

If exporting from Docker to an external machine use the host.docker.internal for POSTGRES_HOST:

Enter information for the following in the Data Exporter block

schema_name - requires developers enter the name of their destination container
table_name - requires developers enter the name of their destination blob path

All other information is handled in the io_config.yml file.

Example Code:

from mage_ai.settings.repo import get_repo_path
from mage_ai.io.config import ConfigFileLoader
from mage_ai.io.postgres import Postgres
from pandas import DataFrame
from os import path

if 'data_exporter' not in globals():
    from mage_ai.data_preparation.decorators import data_exporter


@data_exporter
def export_data_to_postgres(df: DataFrame, **kwargs) -> None:
    """
    Template for exporting data to a PostgreSQL database.
    Specify your configuration settings in 'io_config.yaml'.

    Docs: https://docs.mage.ai/design/data-loading#postgresql
    """
    schema_name = 'your_schema_name'  # Specify the name of the schema to export data to
    table_name = 'your_table_name'  # Specify the name of the table to export data to
    config_path = path.join(get_repo_path(), 'io_config.yaml')
    config_profile = 'default'

    with Postgres.with_config(ConfigFileLoader(config_path, config_profile)) as loader:
        loader.export(
            df,
            schema_name,
            table_name,
            index=False,  # Specifies whether to include index in exported table
            if_exists='replace',  # Specify resolution policy if table name already exists
        )

Delta Lake

Unlike other data exporters, delta lake exporters do not currently configure through the io_config.yml file. They contain the necessary configurations within the exporter block itself. Lets break that down.

Storage Options

'AWS_ACCESS_KEY_ID': Your AWS access key ID.
'AWS_SECRET_ACCESS_KEY': Your AWS secret access key.
'AWS_REGION': The AWS region where your S3 bucket is located.
'AWS_S3_ALLOW_UNSAFE_RENAME': This option allows unsafe rename operations on S3, which might be necessary for some workflows.

Remember Secrets can be stored in Mage’s internal Secrets Manager, .YAML files, or sync directly with Cloud Secret Managers.

Additional Configurations

uri: The S3 URI where the Delta Table is stored.

Example Code:

from deltalake.writer import write_deltalake
if 'data_exporter' not in globals():
    from mage_ai.data_preparation.decorators import data_exporter


@data_exporter
def export_data(df, *args, **kwargs):
    """
    Export data to a Delta Table

    Docs: https://delta-io.github.io/delta-rs/python/usage.html#writing-delta-tables
    """
    storage_options = {
        'AWS_ACCESS_KEY_ID': '',
        'AWS_SECRET_ACCESS_KEY': '',
        'AWS_REGION': '',
        'AWS_S3_ALLOW_UNSAFE_RENAME': 'true',
    }

    uri = 's3://[bucket]/[key]'

    write_deltalake(
        uri,
        data=df,
        mode='append',          # append or overwrite
        overwrite_schema=False, # set True to alter the schema when overwriting
        partition_by=[],
        storage_options=storage_options,
    )

By correctly configuring these components, you can effectively streamline the data loading process into your chosen storage system, whether it be a relational database, a data lake, or a machine learning model repository.
